Name: Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery
Brand: Lu’s Technology Co., Limited
SKU: ML1220 CR1220 3V Lityum Para Pil
Availability: InStock

Evde > Ürünler > Lityum Düğme Hücresi >

Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery

Menşe yeri:

Çin

Marka adı:

OEM

Model numarası:

ML1220 CR1220 3V Lityum Para Pil

Bizimle İletişim

Teklif Et

Ürün Ayrıntıları

Pil serisi:

Düğme tipi şarj edilebilir pil

Pil PN'si:

ML1220

Gerilim:

3.0V

Capactiy:

18 mah

Terminaller:

Pimler, teller, konektör veya Özelleştirilmiş

Malzeme:

Şarj edilebilir Manganez pil

Ödeme ve Nakliye Şartları

Min sipariş miktarı

100 adet

Fiyat

Bargain

Ambalaj bilgileri

Kartonlar

Teslim süresi

5-7 iş günü

Ödeme koşulları

L/C, T/T, Western Union

Yetenek temini

100000 PC/Ay

İlişkili Ürünler

Video

3.0Volt 18mah Cmos Battery ML1220 lithium rechargeable battery ML1220 cion cell battery

En İyi Fiyatı Alın

Video

CR2450 pin lityum pil 600mah 3V siyon lityum pil Özel pil paketi LUS

En İyi Fiyatı Alın

Video

3 Volt 600mah lityum düğme pil CR2450 pimli lityum pil özelleştirmesi

En İyi Fiyatı Alın

Video

Lityum madeni para bataryası CR2430 düğme bataryaları 3V 1200mah ESL lityum batarya OEM

En İyi Fiyatı Alın

Bizimle İletişim

Şimdi iletişime geçin

Ürün Tanımı

Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery ML1220 batteris

Custom Battery Pack ML1220 CMOS Backup Battery 3V lithium battery 3 Volts Li-ion battery ML1220 Rechargeable CMOS Battery with Solder Tabs

Button Battery ML1220 Coin battery ML 1220 Rechargeable 3V battery ML1220 BIOS Backup Batteries ML1220 rechargeable lithium ion batteries 3V lithium battery 1220VL series rechargeable batteries 3v 18 mAh RECHARGEABLE LITHIUM Replacement Battery ML1220 batttery Replacement for RLITH-1-2 Battery ML1220-HJ1 limno2 battery

ML1220 Technical

ML1220 3V rechargeable lithium manganese dioxide button cell battery commonly used for CMOS/BIOS memory backup in laptops

ML1220/FCN Lithium Rechargeable battery ML1220 Industrial Cell Button Battery 3V 18mah cion battery 100% compatible with Panaso nic ML1220-WR equipment

ML1220 3 volt Rechargeable Coin Cell battery ML1220 high-performance rechargeable button battery that delivers superior cycle life compared to traditional CR1220 batteries.

CLASSIFICATION	MANGANESE DIOXIDE LITHIUM RECHARGEABLE BATTERY
BATTERY SYSTEM	COIN TYPE MANGANESE DIOXIDE LITHIUM BATTERY
BATTERY TYPE	ML1220
NOMINAL VOLTAGE	3.0V
NOMINAL CAPACITY	18mAh (ON CONTINUOUS DISCHARGE UNDER 30kΩ load to 2.0V end-point)
STANDARD DISCHARGE CURRENT	0.1mA
MASS	APPROX. 0.85g
SIZE	Φ12.5(+0/-0.3)mm 2.0(+0/-0.2)mm
USABLE TEMPERATURE RANGE	-20ºC~+70ºC
STORAGE TEMPERATURE RANGE	0ºC~30ºC
STORAGE HUMIDITY RANGE	35%~75%

ML1220 Battery can be come with Cable and Connector ML1220 disposable button-type lithium battery

ML1220 Application

This small rechargeable ML1220 battery is commonly used in

electronic devices

such as notebook and laptop computers, PDAs, tablet PCs, digital cameras

and communications equipment.

It is commonly used as a backup clock battery in many timer equipped home electronics

devices.

Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery 1

Coin cell list

Mode	Voltage(V)	Capacity(mAh)	Dimension(mm)	Weight(g)	Chargeable or Non
CR2032	3	220	20.0*3.2	3	Non
CR2032	3	240	20.0*3.2	3	Non
CR1220	3	35	12.5*2.0	0.8	Non
CR1225	3	50	12.5*2.5	0.9	Non
CR1616	3	50	16.0*1.6	1.1	Non
CR1620	3	70	16.0*2.0	1.3	Non
CR1632	3	120	16.0*3.2	1.8	Non
CR2016	3	83	20.0*1.6	1.7	Non
CR2025	3	150	20.0*2.5	2.5	Non
CR2450	3	600	24.5*5.0	6.2	Non
CR3032	3	550	30.0*3.2	7	Non
ML1220	3	17	12.5*2.0	0.8	Yes

Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery 2

Model	Nominal Voltage (V)	Nominal Capacity (mAh)	Max. Discharge Current (mA)	Resistance (mΩ)	Diameter (mm)	Height (mm)	Weight Approx (g)
LIR1025	3.6	6±2	1C		10.0 -0.15	2.5 +0.15	1.1±0.2
LIR1220	3.6	8±2	1C		12.5 -0.2	2.0 +0.35	0.8±0.3
LIR1254	3.6	65±5	1C	≤600	12.0 -0.2	5.4 +0.2	1.8±0.2
LIR1620	3.6	16±2	1C	≤2000	16.0 -0.2	2.0 +0.35	1.2±0.3
LIR1632	3.6	25±2	1C	≤2000	16.0 -0.2	3.2 +0.35	1.7±0.3
LIR1654	3.6	120±5	1C	≤600	16.0 -0.2	5.4 +0.2	2.4±0.2
LIR2016	3.6	18±2	2C	≤2000	20.0 -0.2	1.6 +0.35	1.7±0.3
LIR2025	3.6	25±5	2C	≤2000	20.0 -0.2	2.5 +0.25	2.3±0.3
LIR2032	3.6	40±5	2C	≤600	20.0 -0.2	3.2 +0.35	2.8±0.3
LIR2050	3.6	80±5	2C	≤600	20.0 -0.2	5.0 +0.2	3.8±0.2
LIR2430	3.6	60±5	2C	≤500	24.5 -0.2	3.0 +0.35	3.8±0.3
LIR2450	3.6	120±10	2C	≤450	24.5 -0.2	5.0 +0.35	5.0±0.3
LIR2477	3.6	180±10	2C	≤400	24.5 -0.2	7.7 +0.3	7.0±0.3

Coin Cell Batteries ML1220 lithium and rechargeable battery 3V lithium alloy coin cell batteries 3.0VOLT BR series battery ML1220 battery custom

Cion type rechargeable lithium battery ML1220 3V rechargeable battery 18mah cion cell battery 3
